Easy to Use

Best industry practices and actual operation are often not the same. The G24 is designed to be understood with 5 minutes of training, and programmable to automatically operate according to the industry’s best practices. The Gammaflux Mold Wizard effortlessly guides the user through

(1)  Zone identification and group creation

(2)  Setpoint entry

(3)  Monitor zone configuration

(4)  Sophisticated mold startup functions

(5)  Advanced zone monitor functions

(6)  Heating the mold

(7)  Saving the menu

During this process, the software automatically tunes each zone, engages the plastic leak detection alarm, sets the imminent heater failure alarm and saves everything back to the mold menu automatically after the “good parts” button is confirmed by the operator. The Wizard makes everyone a controller configuration expert.

Detection By Measuring The Actual Wattage

When plastic leaks into the mold, it occupies a former air space. Eliminating the air space creates a heat sink to the surrounding mass. In automatic mode, the controller increases the power to compensate for the loss in heat. The Mold Wizard automatically sets the watt baseline and engages the alarm after the “good parts” part button is confirmed by the operator. Precisely measuring the actual wattage can be the difference between a short trip to the tool room or weeks of lost production.

Troubleshoot Your Mold

Mold Doctor® is an off-line (tool room), advanced troubleshooting tool consisting of four diagnostic tests:

• Wiring Analysis: checks the wiring of the tool. The software clearly tells the user of miswired zones and how to fix them.
• Fault Analysis: quickly identifies the following problems: thermocouple open, thermocouple reversed, thermocouple pinched, open fuse, heater short/wet, heater open, uncontrolled output and ground fault.
• Thermodynamic Analysis: automatically heats all selected zones to a defined setpoint value and cools down. During the heating and cooling process Mold Doctor^® records critical information and reports to the user. Compare zones against one another; major differences in the four key areas (resistance, power consumption, heating and cooling rates) will point you towards a solution. Once the tool is qualified, save a thermodynamic analysis as your known “good parts” baseline. Future problems will be easy to diagnose using the historical mold performance tool.
• Historical Mold Performance: allows the user to easily compare a known “good” thermodynamic analysis baseline to the current “suspect” thermodynamic analysis. Intuitively troubleshoot your mold with hard data.

Calibrate Without a Calibration Expert

Calibrate your controllers in house quickly, easily and without a calibration technician. Using a field calibrator, establish a thermocouple source equivalent to the controller. The difference between the calibrator value and the control screen is the calibration error. The calibration software corrects the error with an accuracy of ± 0.2º F (± 0.1º C).

Create Tip Layout Patterns

Quickly create a cavity map that is saved with the mold menu. The on-screen tools allow the user to create common tip layout patterns instantly. Select zones to study closer and flip the image to quickly identify which zone/cavity to change or investigate.
